Drop Forged Double Coupler

Drop Forged Double Coupler

Short Description:

Drop forged double coupler are usually made of high-quality carbon steel (such as Q235B) through forging process, and have high strength, wear resistance and deformation resistance. It consists of upper and lower coupler main body, bolts, nuts and washers, and is fastened by bolts to achieve right-angle connection. Drop forged double coupler use forging craft, which can enhance metal density and enhance the pressure-bearing capacity of couplers. The surface treatment of couplers is mostly galvanized, which can prevent rust and extend service life. Its bolts can be adjusted to fit different steel pipe diameters and are easy to disassemble. In addition, Drop forged double coupler can be reused which is cost-effective. Drop forged double coupler are mainly used for right-angle connection between scaffolding horizontal tubes and vertical tubes and are commonly used in various construction scenarios such as buildings, bridges, and decoration.

Product Name:Double Coupler

Process Technology:Drop Forged

Application:construction

Design Style:Industrial


Product Detail

Product Tags

Description:

Drop forged double coupler are critical components in modular scaffolding systems, designed to securely connect vertical standards and horizontal ledgers at precise 90-degree angles. These heavy-duty couplers are extensively used in construction projects including high-rise buildings, industrial plants, bridge construction, and maintenance platforms where structural integrity is paramount
The forged manufacturing process enhances the coupler's load-bearing capacity, making it suitable for supporting heavy construction loads and dynamic forces.The electro-galvanized or hot-dip galvanized ensures
corrosion resistance in outdoor and high-humidity environments.
Compliant with international standards (EN 74, BS 1139), drop forged couplers are compatible with most conventional steel tube scaffolding systems. Their reusable nature and simple bolt-tightened design allow for quick assembly and disassembly, significantly improving scaffolding erection efficiency while maintaining safety. The robust construction makes them particularly valuable in formwork support systems and heavy-duty access scaffolding where maximum stability is required.

Type

British Drop Forged Double Coupler

Weight

0.98kg

Diameter

48.3*48.3mm

Material

Q235B steel

Surface Treatment

Electro-galvanized

Craft

Drop Forged

Application

Connect scaffolding horizontal tube and vertical tube


Parameter:

Warranty:1 year

After-sale service:Online technical support/Other

Design Style:Industrial

Project Solution Capacity:Graphic design/Other

Place of Origin:CHINA

Brand name:HKM

Product Name:Acoplador para andamios

Color:Silver/Red/Blue/Green/Others

Technique:Drop Forged

Size:48.3mm/60.3mm

Material:Q235B/SS400



Surface Treatment:/Electro-Galvanized/Hot-Dipped Galvanized

Type: Pressed Sleeve Coupler, Scaffold tube Coupler, Scaffold Sleeve Coupler

Standard: BS1139/EN74

Material: Q235

Surface Treatment: Electro-galvanized, Hot Dip Galvanized

Process Technology: Pressed

MOQ: 5 Tons

Place of Origin: Tianjin, China

Shipping Port: Tianjin Port

Delivery Time: Within 20-30 days after receiving the LC or Deposit

Sample: Available, Sample for Free


Selling Units:Single item

Single package size:10x10x6cm

Single gross weight:1.0kg

Supply Ability: 1000000 pieces per month



FAQ

1.Q:What is the advantage of your company ?
A: We have own factory, which is located in Tianjin,China. We are a leading company in producing and exporting scaffolding products etc. We can produce and deliver your products in a very short time so that can save our cost.

2.Q: How about the price?
A: Really competitive! Our company is near the origin of steel and we have big order amount, so we get cheaper price of steel raw material; low labor cost and near Xingang sea port are also our advantages. The most of all,“less profit but big turnover” is our perpetual business principle.

3.Q: How about the quality of products in your company?
A: Our products are of high quality, and our products get lots of good feedback from our clients all over the world. We will make quality inspection before loading every time. And we usually keep our customer complaints below 1%.

4.Q: Could you provide free samples?
A: Of course, we can provide you with free samples.
