Italian Type Steel Prop

Italian Type Steel Prop

Short Description:

Italian Type Steel Prop is typically manufactured from high-quality carbon steel materials such as Q195 and Q235, ensuring excellent load-bearing capacity and compressive performance. Its standard dimensions cover a variety of specifications, usually with an outer tube diameter of 56mm, an inner tube diameter of 48mm, and a thickness ranging from 1.5mm to 2.5mm. It is an adjustable vertical pipe support with an adjustable and customizable length. Users can adjust the length by inserting high-strength steel pins into the grooves of the outer and inner sections. Additionally, the steel prop is equipped with a rolled thread section with an adjustable nut, making the structure more compact and safer.




  • Feature: Simple and flexible
  • Raw Materials: Q195/Q235/Q355
  • Surface Treatment: Painted/ Powder coated/ Pre galvanized/ Hot dip galvanized
  • Base Plate: Square/flower

Product Detail

Product Tags

Description:

Italian-style steel prop system stands as a benchmark solution for high-performance temporary support in modern construction. Crafted from high-quality Q195/Q235 steel, this system achieves precise height adjustment and exceptional load-bearing capacity through an innovative modular design and a dual adjustment mechanism (thread fine-tuning + steel pin fixation). The product boasts three core advantages: Firstly, its scientific structural design features a combination of a reinforced base and a U head, with optional standard pipe diameters of 48/56mm and 48/60mm, and the length adjustment range can be customized according to different needs. Secondly, it delivers outstanding performance, including strong compressive strength, enabling quick assembly and disassembly as well as repeated use. Thirdly, it offers excellent corrosion resistance and durability, with various surface treatment options such as galvanized,painted and powder coated. Widely applied in scenarios like cast-in-place concrete, formwork reinforcement, and bridge and tunnel prop, it has become the preferred choice in the field of building support due to its excellent stability, safety, and construction efficiency.


Middle East Type Steel Prop
Min Height Max Height Inner Tube Outer Tube Tube Thickness
2.2m 4.0m 48mm 60mm 1.5-4.0mm
2.5m 4.5m 48mm 60mm 1.5-4.0mm
3.6m 5.0m 48mm 60mm 1.5-4.0mm
Spanish Type Steel Prop
Min Height Max Height Inner Tube Outer Tube Tube Thickness
1.6m 2.9m 40mm 48mm 1.5-2.5mm
2.0m 3.6m 40mm 48mm 1.5-2.5mm
2.2m 4.0m 40mm 48mm 1.5-2.5mm
Italian Type Steel Prop
Min Height Max Height Inner Tube Outer Tube Tube Thickness
1.6m 2.9m 48mm 56mm 1.5-2.5mm
2.0m 3.6m 48mm 56mm 1.5-2.5mm
2.2m 4.0m 48mm 56mm 1.5-2.5mm
North America Type Steel Prop
Min Height Max Height Inner Tube Outer Tube Tube Thickness
3'6''(1.06m) 6'(1.83m) 48mm 60mm 1.5-4.0mm
5'9''(1.75m) 10'3''(3.12m) 48mm 60mm 1.5-4.0mm
6'6''(1.98m) 11'(3.35m) 48mm 60mm 1.5-4.0mm
8'6''(2.59m) 13'(3.96m) 48mm 60mm 1.5-4.0mm
10'6''(3.2m) 15'6''(4.72m) 48mm 60mm 1.5-4.0mm
Australian Type Steel Prop
Min Height Max Height Inner Tube Outer Tube Tube Thickness
1.1m 1.9m 48mm 60mm 1.5-4.0mm
2.1m 3.57m 48mm 60mm 1.5-4.0mm
2.1m 3.8m 48mm 60mm 1.5-4.0mm

Parameter:

Product Name: Adjustable Steel Props

Surface Treatment: Galvanized/Painted

Standard: EN12810, EN74, BS1139, etc.

Diameter: 40/48mm, 48/56mm, 48/60mm, 60/76mm

Thickness: 1.5-4.0mm

Length: Can be customized

Packing: According to customer requirements

Delivery time: 10 Days From Stock; 15-30 Days According To QTY

Payment Terms: T/T Or LC

Trade Method: FOB, CIF, CFR, C&F, EXW


Selling Units:Single item

Single package size:15x15x230cm

Single gross weight:10.5kg

Supply Ability: 110000 pieces per month



FAQ

1.Q: Can you provide samples?

A: We can provide samples according to your requirements, but we need to negotiate the sample fee and shipping fee. If you paid the sample fee, we will refund the sample fee after the bulk order is confirmed.

  1. 2.Q:Can you guarantee the quality of your products?

A: Yes. We will do trial production before mass production. 100% QC test will be done before shipment.

3.Q: Where is your factory? Is it possible to visit the factory?

A: Welcome to visit us! Our factory is Tianjin, China.
