This scaffolding system is usually divided into 48 series and 60 series, mainly composed of core components such as vertical poles, horizontal poles, diagonal poles, bases, standard bases and jacks. The following is a detailed introduction to its uses, main accessories, installation details and specific characteristics.
I. Uses of the Scaffolding System
It has a wide range of applications, generally used in the support design of viaducts, tunnels, workshops, building construction, warehouse shelves, basement construction, overpasses and other projects.
II. Main Components of the Scaffolding System
A standard scaffolding system consists of vertical poles, horizontal poles, vertical diagonal poles and several small accessories, which can be produced in different sizes and specifications according to usage scenarios.
1. Vertical Poles
Vertical poles are welded with circular discs with 8 holes: 4 small holes for connecting horizontal poles and 4 punched holes for connecting diagonal poles. They are usually made of Q355B, Q345B, Q355, Q235 and other materials, with a length range of 0.2m to 3.0m, and the surface is generally treated with hot-dip galvanizing + painting.
2. Horizontal Poles
Horizontal poles adopt a standardized self-locking bolt design, and the joints are specially made according to the radian of the steel pipe, which can be directly attached to the vertical pole steel pipe. After the bolt is tightened, a three-point force-bearing structure is formed, with firm connection and high structural strength, which can effectively transmit horizontal force. The system adopts automatic professional welding technology, and the length of horizontal poles ranges from 0.3m to 3.0m.
III. Characteristics of the Scaffolding System
1. Strong Versatility: It can be flexibly assembled into various construction equipment such as single-row, double-row scaffolding, support frames and supporting columns with 0.5m modulus according to construction needs, with multiple sizes and bearing capacities, and can also be erected into arc-shaped frames.
2. Simple Structure and Convenient Assembly/Disassembly: The whole system is built with modular components, and both the basic structure and special accessories can adapt to various building structures.
3. Higher Economy, Labor and Cost Saving: The erection speed of ringlock scaffolding is 50% faster than that of cuplock scaffolding, which can greatly reduce the working time and labor cost of construction personnel, and ultimately reduce the comprehensive project cost.
