Scaffolding Ladder Beam

Scaffolding Ladder Beam

Short Description:

Scaffolding Ladder Beam is a commonly used structural member in construction projects, made of Q235/Q345 scaffolding steel pipe. The outer diameter of the steel ladder beam is 48.3 mm, and the wall thickness is usually 3.0 mm, 3.2 mm or 4.0 mm. Its surface is usually hot-dip galvanized, so it can be reused many times and has excellent long-term corrosion resistance. During construction, the steel ladder beam is fixed by standard scaffolding fasteners, so it is compatible with all scaffolding systems: including couplers scaffolding, ringlock scaffolding, cuplock scaffolding, quick-release scaffolding, etc.


Product Detail

Product Tags

Description:

Scaffolding Ladder Beam is a commonly used structural member in construction projects, with the following characteristics and applications:Product characteristics:
High-strength characteristics: Steel ladder beams are usually made of high-strength steel, with excellent load-bearing capacity, and can support heavy structures and equipment. Its excellent bending and shear resistance can withstand large bending moments and shear forces, providing reliable support for the project. It is particularly suitable for cantilever structures, which can effectively disperse and transfer loads, reduce structural deformation, and ensure the safety and stability of buildings.
Flexible adaptation: Steel ladder beams can be customized according to project requirements to adapt to different spans and load requirements. Its flexible structural characteristics enable it to meet the needs of complex building structures and is widely used in scenes such as bridges, cantilever structures and high-rise buildings.
Typical applications:Industrial facilities: Widely used for heavy machinery support and crane track load-bearing, providing the necessary structural strength and stability.
Civil engineering: Commonly used in temporary structural projects that require additional support, such as tunnel portal support and retaining wall reinforcement.

Item Surface Treatment Specification Width(mm) Length(mm)
Ladder Beam Hot Dipped Galvanized 48.3*3mm 300 1000-6000
Hot Dipped Galvanized 48.3*3.2mm
Hot Dipped Galvanized 48.3*3.6mm
Hot Dipped Galvanized 48.3*4.0mm
Hot Dipped Galvanized 48.3*3mm 305 1000-6000
Hot Dipped Galvanized 48.3*3.2mm
Hot Dipped Galvanized 48.3*3.6mm
Hot Dipped Galvanized 48.3*4.0mm
Hot Dipped Galvanized 48.3*3mm 350 1000-6000
Hot Dipped Galvanized 48.3*3.2mm
Hot Dipped Galvanized 48.3*3.6mm
Hot Dipped Galvanized 48.3*4.0mm

Parameter:

Warranty:1 year

After-sale service:Online technical support/Other

Design Style:Industrial

Project Solution Capacity:Graphic design/Other

Place of Origin:CHINA

Brand name:HKM

Product Name:Ladder Beam

Color:sliver/Others

Technique:Electric Resistance Welding

MOQ:500 pcs

Width:300mm/305mm/350mm/450mm

Adjustable length:1000-6000mm

Thickness:2.75-4.0mm

Material:Q235/Q355

Certification:CE SGS ISO9001

Surface Treatment:Hot Dipped Galvanized

Supporting mode:Scaffolding system
Delivery: Within 10-25 Days or Depends On Your Order Quantity
Payment: TT, LC,DP,OA


Selling Units:Single item

Single package size:100x50x100cm

Single gross weight:25.00kg

Supply Ability: 60000 pieces per month



FAQ

1.Q: Are you trade company or factory?

A: We are manufacturer, Our factory is in Tianjin near port.

2.Q: What certificate do you have?

A: We own CE/ISO/SGS/ certificate.

3.Q: Can you do the official test for the order, which authoritative organization is recommended?

A: Yes, the test can be arranged as per requirement, SGS test is recommended.

4.Q: Can you send us samples before we place the official order, and how to charge it ?

  1. Yes, we could send you samples for free, you just need to pay the freight cost.

5.Q: What is the delivery time for scaffolding?

A: Normal production time will be about 25-30 days, the final delivery time will be confirmed according to the order items and quantities.
